BATON-X6 is a flip open design light controller. Equipped with handle for easy carrying. With15.6 inch touch screen,6 DMX512 outputs,3072 DMX channels.It can be expanded to 16outputs and 8192 DMX channels.It can patch 3000 lighting fixtures.With 10 USB ports and 15 playback fader. Powerful storage, can store up to 400 programs.

1. With clamshell design, compact and lightweight, configuration handle easy to take, screen with buckle, folding more stable, industrial control motherboard, stable and reliable.Equipped with the latest system, the software is more stable and the functions and parameters are more powerful

2.English operation interface and system. The system language can be customized.

3. intel CPU, 120G Golden Solid State Drive, 4G memory,

4. With 6 standard USB ports

5. With 1 15.6 "HD capacitor touch screen, touch sensitive

6. With 1 TCP/IP Gigabit / 100 Mbit/s adaptive network port

7. With 1 HD HDMI video port

8. With 1 VGA video port

9. WIth 1 high quality microphone input port

10. With 1 Hi-Fi audio outlet

11. With 6pcs optically isolated DMX512 signal outlets,3072 DMX512 channels.Can expandable to 16 DMX512 outputs, 8192 DMX512 channels.

12. With 10 12V USB power supply ports, which can directly supply wireless transmitter

13. Fader&encoder with RGB backlight, can customize the color according to the scene

14. Built-in UPS power supply, can be used for 60 minutes without power

15. The whole body surface is treated with high-end technology

16. With 6pcs 5V USB power supply ports

17. 4 wheel with adjustable attributes.

18. Art-Net network expansion port with 4096 channels

19. Support RDM bidirectional communication protocol

20. Provide software to control the console wirelessly directly with mobile phone or tablet

21. 15 playback fader,Can run 80 playback at the same time.

22. Can store 2700 scenes, each multi-step can store unlimited single step

23. It can control 3000 fixture and store 300 fixture group

24. Palette are divided into 10 categories, each of which can store 200 palette. A total of 2000 palette can be stored

25. Can store 400 programs

26. Built-in music player, easy to achieve one-button light show

27. Each attribute of the lamp can be set up independent time and curve calculation, there are 31 curve forms

28. The built-in shape can be set freely, with 190 fixed graphics

29. There are 6 fan modes, and the fan effect can be modified through the Tips dialog box

30. Special dialog box, you can quickly call the color through the color board, color fader or color preset

31. Layout function, simulate field layout emission, promote the control of lamps and lanterns more accurate and convenient

32. You can customize the name of the menu bar, add or delete menu Windows or call multiple Windows in a screen operation, improve the control efficiency

33. Paragraph arithmetic, can be for attributes, time, shape, etc., at will

34. After connecting the luminaire, you can directly change the address code and line and change the location of the luminaire key

35. All performance files, light library and music on the console can be backed up by external U disk

36. With automatic saving function, you can shut down at any time

37. You can set console startup password and screen lock password to protect console data and operations

38. Lamp group, palette, scene can be customized named or graffiti, easy to find the call

39. Use the XML format light library. Light library editor simple operation, can be written directly on the console can also be written on the computer copy into the console

40. The light library can add segment sets and quickly select attribute features

41. Support wired ART-Net function (light simulator), which can be used for practice and simulation programming

42. Support our company touch series console file interworking, online backup

43. The fader can be customized color, adding performance page identification

44. The light show or scene can be set to automatically run on startup or play in a loop

45. Supports UDP/TCP/485 protocol control

46. Product size/weight:435*320*110mm/8.45kg

47. Packing size/weight:580*430*230mm/10kg
